Product Description
The TOSHON CUT 100 IJ 3 Phase IGBT Plasma Cutting Machine is a heavy-duty industrial cutting system designed for reliable and efficient metal cutting applications. With IGBT inverter technology, a 20–100 A output range, and cutting capacity up to 30 mm, it is suitable for fabrication, engineering, construction, maintenance, and industrial workshops.
Key Features
- 3 Phase 415V AC input for industrial applications
- IGBT Module Technology for efficient and stable operation
- 20–100 A adjustable cutting current
- Up to 30 mm cutting thickness
- 15.1 kVA input power capacity
- 0.93 power factor for efficient power utilization
- 4–5 kg/cm² recommended air pressure
- Rugged construction for demanding workshop environments
- Suitable for continuous professional plasma cutting applications
Technical Specifications
| Specification | Details |
|---|---|
| Model | CUT 100 IJ |
| Technology | IGBT Module |
| Phase | 3 Phase |
| Input Voltage | AC 415V ±15% |
| Input Power Capacity | 15.1 kVA |
| No-Load Voltage | 290 V |
| Output Current Range | 20–100 A |
| Rated Input Current | 23.1 A |
| Power Factor | 0.93 |
| Air Pressure | 4–5 kg/cm² |
| Cutting Thickness | 1.0–30.0 mm |
| Net Weight | 36.5 kg |
| Dimensions | 21.5 × 11 × 21.5 inches |
Applications
- Industrial metal fabrication
- Steel structure manufacturing
- Sheet-metal cutting
- Engineering workshops
- Construction and maintenance
- Automotive and machinery fabrication
- General plasma cutting applications
