Product Description
The GASCO Gas Welding Torch is a professional oxy-acetylene welding torch designed for reliable and precise gas welding applications. Its sturdy brass construction, lightweight design, and durable gas valves make it suitable for workshop, fabrication, maintenance, and general metalworking applications.
The torch is available with different tip numbers from 0 to 25, allowing users to select the appropriate tip according to the thickness of Mild Steel (MS) being welded.
Key Features
- Sturdy high-quality brass body for durability and extended service life
- Nylon-sealed gas valves help prevent gas leakage
- Durable valve design for reliable long-term operation
- Lightweight and convenient to handle
- Multiple tip options for different material thicknesses
- Designed for oxy-acetylene gas welding applications
- Suitable for professional workshop and fabrication use
Technical Specifications
| Specification | Unit | Tip 0 | Tip 1 | Tip 2 | Tip 3 | Tip 5 | Tip 7 | Tip 10 | Tip 13 | Tip 18 | Tip 25 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MS Thickness | mm | 0.6 | 0.91 | 1.2 | 2.1 | 2.6 | 3.2 | 3.9 | 4.8 | 6.4 | 8 |
| Tip Number | — | 0 | 1 | 2 | 3 | 5 | 7 | 10 | 13 | 18 | 25 |
| Oxygen Pressure | kg/cm² | 0.14 | 0.14 | 0.14 | 0.14 | 0.14 | 0.28 | 0.28 | 0.28 | 0.42 | 0.42 |
| Acetylene Pressure | kg/cm² | 0.14 | 0.14 | 0.14 | 0.14 | 0.14 | 0.28 | 0.28 | 0.28 | 0.42 | 0.42 |
| Gas Consumption | m³/hr | 0.03 | 0.03 | 0.06 | 0.09 | 0.14 | 0.20 | 0.30 | 0.40 | 0.50 | 0.70 |
Tip Selection Guide
| MS Thickness | Recommended Tip |
|---|---|
| 0.6 mm | Tip 0 |
| 0.91 mm | Tip 1 |
| 1.2 mm | Tip 2 |
| 2.1 mm | Tip 3 |
| 2.6 mm | Tip 5 |
| 3.2 mm | Tip 7 |
| 3.9 mm | Tip 10 |
| 4.8 mm | Tip 13 |
| 6.4 mm | Tip 18 |
| 8 mm | Tip 25 |
Applications
The GASCO Gas Welding Torch is suitable for:
- Oxy-acetylene welding
- Mild steel welding
- Sheet metal welding
- Metal fabrication
- Repair and maintenance
- Workshop welding
- General gas welding applications
Why Choose GASCO Gas Welding Torch?
The GASCO Gas Welding Torch combines a strong brass body, leak-resistant nylon-sealed valves, and lightweight construction to provide dependable performance and easy handling. Its wide range of tip sizes allows the torch to be adapted to different mild-steel thicknesses.
